M12 connectors


According to the anti-interpolation code, the code can be divided into A coding, B coding, C coding, D coding, P coding, S coding, T coding, and X coding.

The shape can be divided into M12 180 degree straight connector, M12 90 degree elbow connection, M12 T type connecting line, M12 Y type connecting line.

At the same time, two types of shielding and unmasking are also given.

According to the number of needles or cores, there are 3 needles, 4 needles, 5 needles, 8 needles, 12 needles or 3 cores, 4 cores, 5 cores, 8 cores and 12 cores.

The outer leather of the cable is PUR, TPE, PVC, etc.

The M12 connectors of xime connector technology conforms to RoHS, CE, UL certification, good quality, reasonable price and short delivery time


M12 connector and cable can be divided into soldering type, screw terminal type according to the connection methods. According to assembly methods, it can be divided intoassembly type,molding type,panel mounting type. According to encoding mode, it can be divided intoA coding,B coding,C coding,D coding,P coding,S coding,T coding,X coding. According to the shape, it can be divided into180 degree straight M12 cable,90 degrees right angled M12 connector cable,M12 T shape cables,M12 Y shape cables. At the same time it is also classified as two types of shielded and not shielded M12 cable. According to the pin or core number, there are3 pin,4 pin,5 pin,8 pin,12 pin or 3 pole, 4 pole, 5 pole, 8 pole, 12 pole. The material of M12 cable jacket has PUR, PVC and so on.


General information

Standard: IEC 61076-2-101
Ambient temperature: -20℃ ~ +80℃
Connector insert: TPU
Connector contacts: Brass with gold plated
Connector over-molding: TPU
Coupling nut/screw: Zinc alloy with nickel plated
Insulation resistance: ≥100MΩ
Contact resistance: ≤5mΩ
Shielding: optional
IP rating: IP67/IP69K in locked condition

Electrical data
core number type Rated current Rated voltage Conductor specification wire jacket Wire length-tail treatment
A/C D/C AWG mm²
03 pins A/B/C 4A 250V 250V 22 0.34 PUR/PVC Customized
04 pins A/B/C/D 4A 250V 250V 22 0.34 PUR/PVC
05 pins A/B/C 4A 60V 60V 22 0.34 PUR/PVC
06 pins C 2A 30V 30V 24 0.25 PUR/PVC
08 pins A 2A 30V 30V 24 0.25 PUR/PVC
12 pins A 1.5A 30V 30V 26 0.14 PUR/PVC
17 pins A 1.5A 30V 30V 26 0.14 PUR/PVC






M12 circular connector, made by international standard, number of cores has 3 pin 4 pin 5 pin 8 pin,12 pin. According to international standards, it is used in various fields and is one of the major electronic components connecting ximeconn

M12 connector with a high signal integrity and excellent performance is a type of high standard connector conforming to the European Union standard.

M12 circular connector, combining characteristics of power cable and data cable, with the characteristics of little occupied area and reducing the cost of installation, is suitable for process automatic control and industrial application, automation equipment, electronic equipment, electronic instrumentation, sensors, commercial transportation, and military/aerospace applications.

Using 4/5/8 contacts, each contact is able to carry the highest current 4A.

Products is made by injection molding technology and it can ensure perfect IP67 seal class and provide the reliable stress relieving capacity.

Classified according to outline shape: circular electric connector (also divided into M12 connector, M8 connectors), rectangle electric connector (overloaded connector).

M12 connectors have the effect of signal connection between all kinds of instruments and equipment.

M12 cable Catalogue for Sensor, Actuator, Automation, Industry Ethernet Applications
