M9 connector

M9 connector

sensor waterproof connectors M5,M8,M9,M12,M16,M23,providing threaded waterproof connectors,m12 connectors,electronic harness design and development,2D 3D design services,MC4 connector cables,M8 connector,M12 adapter splitter cables,push pull connector,solar connector,Medical plugs equipment connector,military equipment waterproof box,car wiring harness,etc.

  • description
  • Application
  • Case
  • Download



Information:

Standard

IEC 61076-2-101 Ed 3.0

Connector body

PA66+GF or TPU

Connector Contacts

Brass with gold plated

Coupling Screw

Brass with nickel plated

Insulation Resistance

≥100MΩ

Waterproof Rating

IP67/IP68








Electrical Character:

Contacts

Rated voltage



Rated current

Contact Resistance



A/C

D/C





2 Pins 125V 125V 4A ≤3mΩ

3 Pins

125V

125V

4A

≤3mΩ

4 Pins

125V

125V

3A

≤3mΩ

5 Pins

125V

125V

3A

≤3mΩ

7 Pins 125V 125V 1A ≤3mΩ

8 Pins

125V

125V

1A

<3mΩ


M9 agilia cable to VGA
