M12 Field Wirable Assembly

* 3/4/5/6/8/12/17 Poles available
* A/B/C/D/S/T/X coding
* Shielded or unshielded
* Field wirable assembly type, with solder or screw joint termination
* IP67/IP68/IP69K in locked condition
* Cable length customized, PUR/PVC cable jacket
M12 Circular connector Tried and tested plug connectors,12 years of experience in the field,Available for assembly with cross-sections of 10mm²,Also available as ready made leads,Leads made to customer's specifications.

  • description
  • Application
  • Case
  • Download



 M12 Circular connector

* 3/4/5/6/8/12/17 Poles available

* A/B/C/D/S/T/X coding
* Shielded or unshielded
* Field wirable assembly type, with solder or screw joint termination
* IP67/IP68/IP69K in locked condition

* Cable length customized, PUR/PVC cable jacket


Electrical data
core number type Rated current Rated voltage Conductor specification wire jacket Wire length-tail treatment
A/C D/C AWG mm²
03 pins A/B/C 4A 250V 250V 22 0.34 PUR/PVC Customized
04 pins A/B/C/D 4A 250V 250V 22 0.34 PUR/PVC
05 pins A/B/C 4A 60V 60V 22 0.34 PUR/PVC
06 pins C 2A 30V 30V 24 0.25 PUR/PVC
08 pins A 2A 30V 30V 24 0.25 PUR/PVC
12 pins A 1.5A 30V 30V 26 0.14 PUR/PVC
17 pins A 1.5A 30V 30V 26 0.14 PUR/PVC
